A closed figure having four sides formed by joining four points, no three of which are collinear, in an order is called quadrilateral. For example: Quadrilateral is the union of four line segments that join four coplanar points; no three of which are collinear and each segment meet exactly two other lines, each at their end point. A quadrilateral is convex if each of the internal angle is less than 180˚. Otherwise it is concave quadrilateral. 3.5.2 Properties of quadrilateral Let ABCD be a quadrilateral.
Adjecent sides and opposite sides:
Adjacent angles and opposite angles:
Diagonal Property: The diagonal AC divides the quadrilateral into two triangles, namely, triangles ABC and triangles ADC. Name the triangles formed when the diagonal BD is drawn. Angle Sum Property: Theorem 1: The sum of the angles of quadrilateral is 360˚ Given: ABCD is a quadrilateral To prove: ∠A + ∠B + ∠C + ∠D = 360˚ Construction: Draw the diagonal AC Proof: In triangle ADC, ∠1 + ∠2 + ∠3 = 180˚(angle sum property) In triangle ABC, ∠4 + ∠5 + ∠6 = 180˚ Adding these two, ∠1 + ∠2 + ∠3 + ∠4 + ∠5 + ∠6 = 360˚ But , ∠1 + ∠4 = ∠A and ∠3 + ∠6 = ∠C. Therefore, ∠A + ∠D + ∠B + ∠C = 360˚ Thus, the sum of the angles of quadrilateral is 360˚ Example 1: The four angle of a quadrilateral are in the ratio 2:3:4:6. Find the measures of each angle. Solution: Given: The ratio of the angles is 2:3:4:6 To find: The measures of each angle. Observe that 2 + 3 + 4 + 6 = 15. Thus 15 parts accounts for 360˚. Hence, 15 parts à 360˚ 2 parts à (360˚/15) * 2 = 48˚ 3 parts à (360˚/15) * 3 = 72˚ 4 parts à (360˚/15) * 4 = 96˚ 6 parts à (360˚/15) * 6 = 144˚ Thus the angles are 48˚, 72˚, 96˚, 144˚ Example 2: In a quadrilateral ABCD, ∠A and ∠C are of equal measure; ∠B is supplementary to ∠D. Find the measure of ∠A and ∠C. Solution: We are given ∠B + ∠D = 180˚. Using angle sum property of a quadrilateral, we get, ∠A + ∠C = 360˚- 180˚ = 180˚ Since, ∠A + ∠C are of equal measure, we obtain ∠A = ∠C = 180˚/2 = 90˚ Example 3: Find all the angles in the given quadrilateral below: Solution: We know that, ∠P + ∠Q + ∠R + ∠S = 360˚. Hence, x + 2x + 3 + x + 3x – 7 = 360˚ This gives, 7x – 4 = 360˚ or 7x = 364˚ Therefore, x = 364˚/7 = 52˚ We obtain ∠P = 52˚; ∠R = 52˚; ∠Q = 2x + 3 = 107˚; ∠S = 149˚. Check that, ∠P + ∠Q + ∠R + ∠S = 360˚ EXERCISE 3.5.2
Solution: Let ∠A and ∠B be x, ∠C=70° and ∠D = 130° ∠A + ∠B + ∠C + ∠D = 360° (Theorem 7) x + x + 70° + 130° = 360° 2x = 360° − 200° X = 160°/2 = 80° ∴ ∠A = 80° and ∠B = 80°
Solution: ∠P + ∠Q = 180° (Supplementary angles) ∠P + ∠Q + ∠R + ∠S = 360° (Theorem 7) 180° + 125° + ∠S = 360° ∠S = 360°−(180° + 125°) ∠S = 360°−305° ∠S=55°
90°. Find the measures of the other three angles. Solution: Let the angles be 2x, 3x, 5x. ∠A + ∠B + ∠C + ∠D = 360° 2x + 3x + 5x + 90° = 360° 10x = 360°−90° x = 270°/10 x = 27° ∴ The angles are , ∠A = 2x = 2×27 = 54° ∠B = 3x = 3×27 = 81 ∠C = 5x = 5×27 = 135° 4.In the adjoining figure, ABCD is a quadrilateral such that ∠D + ∠C =100°. The bisectors of ∠A and ∠B meet at ∠P. Determine ∠APB. Solution: AP and BP are angular bisectors ∠D + ∠C = 100° To find: ∠APB Proof : ∠A + ∠B + ∠C + ∠D = 360° (Theorem 7) ∠A + ∠B + 100° = 360° ∠A + ∠B = 360° − 100° Multipyling by 12 , 12 × ∠A + 12 × ∠B = 12 × 260 a + b =130° In Δ APB, a + b + ∠P = 180° ∠P = 180° − 130° ∠P = 50° 3.5.3 Trapezium The set of fundamental have a pair of opposite sides which are parallel. Such a quadrilateral is known as trapezium. For example: Example 4: In the figure ABCD, suppose AB||CD; ∠A = 65° and ∠B = 75°. What is the measure of ∠C and ∠D? Solution: Observe that, ∠A + ∠D = 180° (a pair of adjacent angles of a trapezium is supplementary.) Thus, 65° + ∠D = 180° This gives, ∠D = 180° – 65° = 115° Similarly, ∠B + ∠C = 180°, which gives 75° + ∠C = 180°. Hence, ∠C = 180° – 75° = 105° Example 5: In an isosceles trapezium PQRS, ∠P and ∠S are in the ratio 1:2. Find the measure of all angles. Solution: In an isosceles trapezium base angles are equal; ∠P = ∠Q. Let ∠P = xº and ∠S = 2xº. Since, ∠P + ∠S = 180º (one pair of adjacent angles of a trapezium is supplementary). We get, x + 2x = 180º x = 180º/3 = 60º Hence, ∠P = 60º and ∠S = 2 x 60º = 120º. Since, ∠P = ∠Q, we get, ∠Q = 60º. But, ∠Q + ∠R = 180º. Hence, we get, ∠R = 180º – 60º = 120º EXERCISE 3.5.3 Solution: ∠P + ∠S = 180° (Supplementary angles) ∠S = 180° − 70° = 110° ∠Q + ∠R = 180° (Supplementary angles) ∠R = 180° −80° = 100° 2. In a trapezium ABCD with AB || CD. It is given that AD is not parallel to BC. Is ΔABC ≅ Δ ADC? Give reasons. Solution: In Δ ABC and Δ ADC, (1) AC = AC (Common side) (2) ∠BAC = ∠ACD (Alternate angles, AB || CD) 3. In the figure, PQRS is an isosceles trapezium; ∠SRP = 30°, and ∠PQS=40° Calculate the angles ∠RPQ and ∠RSQ. Solution: Data:PQRS is an isosceles trapezium, PS = RQ and ∠P = ∠Q ∠SRP = 30° and ∠PQS = 40° To find : ∠RPQ and ∠RSQ Proof: ∠RPQ = ∠SRP = 30° (Alternate angles, PQ || SR) ∠RSQ = ∠PRS = 40° (Alternate angles, PQ || SR) 4. Proof that the base angles of an isosceles trapezium are equal. Solution: Data: ABCD is an isosceles trapezium. To Prove: ∠A = ∠B Construction: Join the diagonal BD and AC. Proof : In Δ ACB and ΔBDA (1) BC = AD (Isosceles trapezium) (2)AC = BD (ISosceles trapezium) (3) AB = AB (Common side) ∴ ACB ≅ Δ BDA (SSS postulate) ∴ ∠A = ∠B (Congruency property) 5. Suppose in a quadrilateral ABCD, AC= BD and AD = BC. Prove that ABCD is a trapezium. Solution: Data: ABCD is a quadrilateral, AC = BD and AD = BC To prove: ABCD is trapezium Proof: In Δ ADB and Δ BCA (1) AD = BC (Data) (2) AC = BD (Data) (3) AB = AB (Common side) ∴ Δ ADB ≅ Δ BCA (SSS postulate) ∴ ∠A = ∠B (Congruency property) AC = BD (Data), AD = BC (Data) ∴ ABCD is an isosceles trapezium 3.5.4 Parallelograms Look at the following sets of quadrilaterals: A quadrilateral in which both the pairs of opposite sides are parallel is called a parallelogram. Proposition 1: In parallelogram, opposite sides are equal and opposite angles are equal. Proof: Let ABCD is a parallelogram. Join BD. Then ∠1 = ∠2 and ∠3 = ∠4. In triangles ABD and CBD, we observe that, ∠1 = ∠2 ; ∠4 = ∠3 , BD(common) Hence, ΔABD ≅ Δ CDB (ASA postulate). It follows that, AB = DC, AD = BC and ∠A = ∠C. Similarly join AC, and we can prove that, ΔADC ≅ Δ CBA. Hence, ∠D = ∠B Example 6: The ratio of two sides of parallelogram is 3:$ and its perimeter is 42cm. Find the measures of all sides of the parallelogram. Solution: Let the sides be 3x and 4x. Then the perimeter of the parallelogram is 2(3x + 4x) = 2 x 7x = 4x. The given data implies that, 42 = 14x, so, that, x = 42/14 = 3. Hence the sides of the parallelogram are 3 x 3 = 9cm and 3 x4 = 12cm Example 7: In the adjoining figure, PQRS is a parallelogram. Find x and y in cm. Solution: In a parallelogram, we know, that the diagonals bisect each other. Therefore SO = OQ. This gives 16 = x + y. Similarly, PO = OR, so that 20 = y + 7. We obtain y = 20 – 7 = 13cm. Substituting the value of y in the first relation, we get 16 = x + 13. Hence x = 3cm EXERCISE 3.5.4 1.The adjacent angles of a parallelogram are in the ratio 2:1 Find the measures of all the angles. Solution: Let the angles be 2x and x ∠A + ∠B = 2x + x = 180° (Adjacent angles of parallelograms are supplementary) 2x + x = 180° 3x = 180° X = 180°/3 = 60° ∴ ∠A = 2x = 60×2 = 120° ∴ ∠B = 60° ∴ ∠C = ∠A = 120° (Opposite angles of parallelogram) ∠D = ∠B = 60° (Opposite angles of parallelogram) 2. A field is in the form of a parallelogram, whose perimeter is 450 m and one of its sides is larger than the other by 75m. Find the lengths of all sides Perimeter = AD + DC + CB + BA 450 = x + x + 75 + x + x + 75 450 = 4x + 150 450 – 150 = 4x 300𝑥 = x X = 75 ∴ Side = 75m(x) ∴ Opposite side = x + 75 = 75 + 75 = 150m 3. In the figure, ABCD is a parallelogram. The diagonals AC and BD intersect at O; and ∠DAC = 40°, ∠CAB = 35°, and ∠DOC = 10°. ∠ADC, ∠ACB, and ∠CBD.
Solution: Data: ABCD is a parallelogram AD || BC and DC || AB. The diagonals AC and BD intersect at O ∠DAC = 40°, ∠CAB = 35° and ∠DOC = 110° To find : (1) ∠ABO (2)∠ADC (3)∠ACB (4) ∠CBD Proof: ∠DAC + ∠CAB = ∠A 40° + 35 = ∠A ∠A = 75° ∠C = ∠A = 75° (Opposite angles of parallelogram are equal) ∠D + ∠A = 180° (Supplementary angles) ∠D = 180°−75° = 105° ∠B = ∠D = 105° (Opposite angles of parallelogram are equal) ∠DOC = ∠AOB = 110° (Vertically opposite angles) In Δ AOB, ∠A + ∠O + ∠B = 180° (Sum of all angles of a Δ is 180°) 35° + 110° + ∠B = 180° ∠B = 180°-145° (1) ∠ABO = 35° (2)∠ADC = 105° (Proved) (3)∠ACB = ∠CBD = 40° (Alternate angles, AD || BC) ∠CBD = 105°-35° (4) ∠CBD = 70° (1)∠ABO = 35° (2) ∠ADC = 105° (3)∠ACB = 40° (4) ∠CBD = 70° 4. In a parallelogram ABCD, the side DC is produced to E and ∠BCE = 105°. Calculate and ∠A, ∠B, ∠C and ∠D. Solution: ∠BCD + ∠BCE = 180° (Linear pair) In ABCD, ∠A = ∠C = 75° (Opposite angles of parallelogram) ∠ABC = ∠BCE = 105° (Alternate angles, AB || DE) ∠D = ∠B = 105° (Opposite angles of parallelogram) 5. Prove logically the diagonals of a parallelogram bisect each other. Show conversely that a quadrilateral in which diagonals bisect each other is a parallelogram. Solution: Data: ABCD is a parallelogram ( ║ln) To Prove : AO = OC and DO = OB Proof: In ΔABO and DOC (1)AB = DC (Opposite sides of angles) (2) ∠AOB = ∠DOC (V.O.A) (3) ∠ABD = ∠BDC (Alternate angles AB ||CD) ∴ ΔABO ≅ ΔDOC (ASA portulate) ∴ AO = OC & DO = BO (Congruence properties) 6. In a parallelogram KLMN, ∟K = 60°. Find the measure of all the angles. Solution: ∠M = ∠K = 180° (Supplementary angles) ∠N = 180°−60° = 120° ∠M = ∠K = 60° (Opposite angles of parallelogram) ∠L = ∠N = 120° 7. Let ABCD be a quadrilateral in which ∠A = ∠C and ∠B = ∠D. Prove that ABCD is a parallelogram. Solution: Data: ∠A = ∠C and ∠D = ∠B To Prove: ABCD is a parallelogram Proof: ∠A + ∠B + ∠C + ∠D = 360° x + y + x + y = 360° 2x + 2y = 360° 2(x + y) = 360° x + y = 360°/2 = 180° Adjacent angles are supplementary ∴ ABCD is a parallelogram. 8. In a quadrilateral ABCD, suppose AB = CD and AD = BC. Prove that ABCD is a parallelogram.Solution: Data: ABCD is a quadrilateral, AB = DC, AD = BC To Prove : ABCD is a parallelogram Construction: Join DB
Proof: In Δ ABD and Δ DBC (1) DB = DB (Common side) (2) AD = BC (Data) (3) AB = DC (Data) ∴ ABD ≅ Δ DBC (SSS postulate) ∴ ∠DBA = ∠BDC (Congruency property) But they are alternate angles These we have AB ║ DC ∴ ∠ADB = ∠DBC (C.P) But they are alternate angles These we have DA ║ BC ∴ ABCD is a parallelogram. 3.5.5 Special kinds of paralellograms Rectangle: A rectangle is a parallelogram whose all angles are right angles. Diagonal properties of a rectangle: (i) The diagonals of a rectangle are equal (ii) The diagonals of a rectangle bisect each other. Example 8: In a rectangle XYWZ, suppose O is the point of intersection of its diagonals. If ∠ZOW = 110º. Calculate the measure of ∠OYW. Solution: We know, ∠ZOW = 110º. Hence, ∠WOY = 180º – 110º = 70º (supplementary angles) Now, OYW is an isosceles triangle, as OY = OW. Hence, ∠OYW = ∠OWY = (180º – 70º)/2 = 110º/2 = 55º Rhombus: A rhombus is a parallelogram in which all the four sides are equal. Example 10: The diagonals of a rhombus are 24cm and 10cm. Calculate the area of the rhombus. Solution: We are given that AC = 24cm; BD = 10cm. We know that the diagonals of a rhombus bisect each other at right angles. Let O be the point of intersection of these diagonals. Then we have AO = CO = 12cm and BO = DO = 5cm. We also know that AOD is right angled triangle. Hence the area of triangle AOD is 1/2 x OA x OD = 1/2 x 12 x 5 = 30 cm2 Since a rhombus has four congruent right triangles, is area is 4 x 30 = 120 cm2 Square A square is a parallelogram, in which (i) in which all the sides are equal (ii) each angle is right angle (iii) diagonals are equal (iv) diagonals bisect at right angles. Example 12: A field is in the shape of a sqaure with side 20m. A pathway of 2m width is surrounding it. Find the outer perimeter of the pathway. Solution: Width of the pathway is 2m. Length of the side of the outer sqaure = (20 + 2 + 2) = 24m Hence, perimeter 4 x 24 = 96m Kite: Kite is a quadrilateral in which two of isosceles triangles are joined along the common base. Example 14: In the figure PQRS is a kite; PQ = 3cm and QR = 6cm. Find the perimeter of PQRS. Solution: We have PQ = PS = 3cm, QR = SR = 6cm. Hence, the perimeter = PQ + QR + RS + PS 3 + 6 + 6 + 3 = 18cm EXERCISE 3.5.5 1. The sides of the rectangle are in the ratio 2:1. The perimeter is 30 cm. Calculate the measure of all the sides. Solution: ABCD is a rectangle Let AB:BC = 2:1 ∴ AB = 2x and BC = x Perimeter of the rectangle = 2(1+b) 2(1+b) = 30 2(2x+x) = 30 2×3x = 30 6x = 30 x = 306 = 5 2x = 2×x = 2×5 = 10 1x = 1×4 = 1×5 = 5 AB = 10m; BC = 5cm CD = 10cm; DA = 5cm 2. In the adjacent rectangle ABCD, ∠OCD = 30°. Calculate ∠BOC. What type of triangle is BOC? Solution: ABCD is a rectangle Diagonals AC and BD bisect each other at O and AC = BD. AO = OC = BO = OD OCD = ODC = 30° On ΔCOD, ∠ODC + ∠OCD + ∠COD = 180˚ 30° + 30° + ∠COD = 180° 60° + ∠COD = 180° ∴ ∠COD = 180˚ – 60˚ =120° ∠COD + ∠COB = 180˚ ∠COB = 180˚ – 120˚ ∠COB = 60° ∴ Δ BOC is an isosceles triangle
Solution: All rectangles have all the properties of parallelograms but a parallelogram May not have all the properties of a rectangle.
Solution: Data : ABCD is a rectangle. AC and BD are the diagonals. To Prove: AC = BD Proof : In ΔABC and Δ ABD ∠ABC = ∠BAD [90°] BC = AD [Opp. Sides] AB = AB [Common side] ∴ ΔABC ≅ ΔABD [SAS] ∴ AC = BD [CPCT]
Solution: ABCD is a rectangular park let AB : BC = 4 : 3 ∴ AB = 4x and BC = 3x Area of rectangle = 1×b 4x × 3x = 1728 12x2 = 1728 X2 = 144 X = √144 = 12 Length = 4x = 4×12 = 48m Breadth = 3x = 3×12 = 36m Perimeter of a rectangle = 2(l + b) 2(48 + 36) = 2×84 = 168m Cost of fencing = perimeter ×Rate = 168 ×2.50 = Rs.420
Shape (see fig) whose parallel sides have lengths 15 m and 25 m. What fraction of the yard is occupied by the flower bed? Solution: ABCD is a rectangular yard AEFB is a trapezium AB ║ EF AB = 25 m and EF = 15m AD = BC = 5m Area of rectangle = ½ × b = 25×5 = 125m² Area of each flower bed = ½ ×b×h = ½ ×5×5 = (25/2) m² Area of both flower beds = 2× (25/2) = 25m² Fraction of flower beds to yard = 25/125 = 1/5 7. In a rhombus ABCD ∠C = 70°. Find the other angle of the rhombus. solution: ABCD is a rhombus ∠C = 70° ∠A + ∠B =180° (adjacent angles) 70 + ∠B = 180° ∠B = 180 − 70 = 110° ∠B = ∠D = 110° ∴ ∠A = 70°; ∠B = 110° ; ∠D = 110° 8. In a rhombus PQRS, ∠SQR = 40° and PQ = 3 cm. Find ∠SPQ, ∠QSR and the perimeter of the rhombus. Solution: PQRS is a rhombus∠SQR = 40° and PQ = 3cm ∠SQR = 40° and PQ = 3cm ∠PQS = ∠SQR = 40° ∠PQS = 40° (diagonal bisector angles ) 3 cm But ∠PQS = ∠QSP [PQ = PS] ∴ ∠QSP = 40° In Δ PQS, ∠PQS + ∠QSP + ∠SPQ = 180° 40° + 40° + ∠SPQ = 180 ∠SPQ = 180 −80 = 100° ∴ ∠SPQ = 100° In a rhombus PQ = QR = RS = SP = 3cm Perimeter of the Rhombus PQRS = 3×4 = 12cm 9. In a rhombus PQRS, if PQ = 3x -7 and QR = x + 3, find PS. Solution: In a rhombus all sides are equal PQ = QR = RS = SP ∴ PQ = QR 3x -7 = x + 3 3x -x = 3 + 7 2x = 10 X = 5 PS = x+3 = 5+3 = 8 cm 10. Let ABCD be a rhombus and ∟ABC = 124°. Calculate ∟A, ∟D and ∟C. In a rhombus, opposite angles are equal Solution: ∠B = ∠D = 124° ∠A + ∠B =180° Consecutive angles ∠A + 124° = 180° ∠A + 124° = 180° ∠A = 180-124=56° ∴ ∠A = 56° ; ∠B = 124° and ∠C = 56° 11. Rhombus is a parallelogram: justify. Solution: Rhombus has all the properties of parallelogram i.e a) Opposite sides are equal and parallel. b) Opposite angles are equal. c) Diagonals bisect each other ∴ Rhombus is a parallelogram. 12. In a given square ABCD, if the area of triangle ABD is 36 cm2 , find (i) the area of triangle BCD; (ii) the area of the square ABCD. Solution: ABCD is a square Bd is the diagonal The diagonal divides the square into two congruent triangles ∴ Δ ABD ≅ Δ BCD D C ∴ Area of Δ ABD =area of Δ BCD Area of Δ ABD= 36 cm² (given) ∴ Area of Δ BCD = 36cm² Area of the square ABCD = Area of Δ ABD + Area of ΔBCD =36cm² +36cm² Area of the squre ABCD =72cm²13. The side of a square ABCD is 5 cm and another square PQRS has perimeter equal to 40cm. Find the ratio of the area ABCD to the area of PQRS. Solution: = 4×5 = 20 Ratio of (perimeter of ABCD)/(Perimeter of PQRS) = 20/40 = 1/2 or 1:2 Area of ABCD = (side)² = (5)² = 25cm Side of PQRS = perimeter/4 = 40/4 = 10cm Area of PQRS = (side)² = (10)² = 100cm² Ratio of (Area of ABCD)/(Area of PQRS) = 25/100 = 1/4 or 1:4 14. A square field has side 20m. Find the length of the wire required to fence it four times. Solution: Length of one side of the square = 20 Rs Length of wire required to fence one round = 4×20 Length of wire required to fence four rounds = 80m = 4×80m = 320m 15. List out the differences between square and rhombus. Solution: Square 1. All the angles are equal 2. Diagonals are equal 3. Area = side × side=(s)² Rhombus
2. Diagonals are unequal 3. Area= 1/2 × Product of diagonals = 1/2 x d1 d2 Solution: Let the length of rectangles be ‘a’ and breadth be ‘b’ Side of outer square –(a+b) units Side of outer square (a-b) units Area of outer square = 4 times area of inner square Area of ABCD = 4(Area of PQRS) (a + b)² = 4(a-b) (a + b) = 2(a – b) 2a – 2b = (a + b) 2a – a = b + 2b a = 3b a/b = 1/3 or 1 : 3 |
